project | Parameter details |
Basic specification |
|
Product model: | S1 Pro（Phantas S1 Pro / SIPRO） |
Body size | 540 mm × 440 mm× 617 mm |
Net weight of fuselage | 53 kg |
Operating noise: | < 65 dB(A) |
Scrub floor cleaning width: | 330 mm |
Sweeping cleaning width: | 410 mm |
Maximum theoretical efficiency (scrubbing/dusting) | 950 ㎡/h |
Maximum theoretical efficiency (sweeping and suction) | 1180 ㎡/h |
Water tank battery life coverage area | > 1000 ㎡ |
Welt cleaning distance | 0 mm（Zero welt design） |
Suitable for floor type | Hard floors, short-pile carpets (support automatic material recognition) |
Competing for water tank capacity | 11.5 L |
Sewage tank capacity | 10.5 L |
Dust bag contents: | 6 L（Can hold 3-7 days of daily waste） |
Dust box contents | 0.7 L |
Maximum operating speed | 0.8 m/s |
Climbing ability | 8°（Approximately 14% grade） |
Minimum pass width: | 600 mm |
Minimum turning width: | 750 mm |
Minimum passing height: | 650 mm |
Battery type | Lithium iron phosphate battery（LEP） |
Battery life (scrubbing mode) | 4.5 h |
Battery life (vacuum mode) | 4 h |
Battery life (sweeping mode) | 14 h |
Battery life (dust pushing mode) | 10 h |
Charging time | about 2 h |
Positioning method | laser SLAM |
Sensor configuration | Lidar, depth camera, RGB camera, anti-collision sensor, anti-fall sensor |
Core functions | Autonomous mapping, intelligent path planning, dynamic obstacle avoidance, automatic recharging, cross-floor operations (optional elevator control module) |
